n8n Workflows Automation

n8n Workflows

This guide is for testing the LayerProof n8n node locally, separate from the main service-poc dev flow.

LayerProof can run inside a local or self-hosted n8n instance through the published community node package n8n-nodes-layerproof, so you do not need to call the API manually.

Before You Start

Make sure you have:

• Docker
• Docker Compose
• a local folder for your n8n project
• a valid LayerProof API key

This document already includes the full local Docker setup below.

Important:

• this guide is for local or self-hosted n8n
• use the API origin only for Base URL
• do not append /api or /api/v2

Examples:

• correct: https://api.dev.layerproof.app
• incorrect: https://api.dev.layerproof.app/api/v2

Local Setup

1. Create a local n8n project

mkdir test-n8n-layerproof
cd test-n8n-layerproof

2. Create docker-compose.yml

services:
  n8n:
    image: n8nio/n8n:stable
    container_name: n8n-layerproof
    ports:
      - "5678:5678"
    environment:
      - TZ=Asia/Ho_Chi_Minh
    volumes:
      - ./n8n-data:/home/node/.n8n

3. Start n8n

docker compose up -d

4. Install the LayerProof node package

docker exec -it n8n-layerproof sh -lc 'mkdir -p /home/node/.n8n/nodes && cd /home/node/.n8n/nodes && npm init -y && npm install --legacy-peer-deps n8n-nodes-layerproof@latest'

5. Restart n8n

docker restart n8n-layerproof

6. Verify the package is installed

docker exec -it n8n-layerproof sh -lc "ls -la /home/node/.n8n/nodes/node_modules/n8n-nodes-layerproof"

7. Open n8n

http://localhost:5678

Add the Node in n8n

Use this flow:

1. Create a new workflow
2. Add Manual Trigger
3. Click the + button after the trigger
4. Search for LayerProof

• LayerProof is not a trigger node
• do not search for it from the first trigger picker screen

Create LayerProof Credentials

1. Add the LayerProof node

2. Create a new credential for LayerProof API

3. Enter:

   • API Key: your LayerProof API key
   • Base URL: your LayerProof API origin

4. Save the credential

Expected values:

• API Key: sk_live_...
• Base URL: https://api.dev.layerproof.app

First Test

Start with a simple read-only call:

1. Add Manual Trigger
2. Add LayerProof
3. Select your credential
4. Set:
   • Resource: Project
   • Operation: List
5. Optionally set Limit to 1
6. Execute the node

If setup is correct, the response should contain:

• data
• next_cursor
• has_more

Common Mistakes

• using the wrong Base URL
• adding /api or /api/v2 into Base URL
• pointing to the web app instead of the API origin
• installing the package in the wrong directory
• forgetting to restart n8n after install
• searching for LayerProof in the trigger picker

Troubleshooting

The node does not appear

Check that:

• the package installation finished successfully
• community nodes are allowed in your local n8n instance
• you reloaded the editor or restarted n8n

Credential test fails

Check that:

• the API key is valid
• the Base URL is correct
• the Base URL does not include /api or /api/v2

The API returns 403

This usually means the API key is valid, but the account does not have the required LayerProof public API access.

The API returns HTML instead of JSON

This usually means the Base URL points to the frontend app instead of the API origin.

Update the Package Later

docker exec -it n8n-layerproof sh -lc 'cd /home/node/.n8n/nodes && npm update --legacy-peer-deps n8n-nodes-layerproof'
docker restart n8n-layerproof

Summary

To test LayerProof in local n8n:

1. Start a local n8n Docker project
2. Install n8n-nodes-layerproof
3. Restart n8n
4. Add the LayerProof node
5. Create LayerProof API credentials
6. Test with Project -> List
